OPT+IPL+ELIGHT+RF+ND YAG LASER
Working Systems:A: OPT SHR system: adopts the most advanced OPT (optimal pulse technology) system for fast hair removal.
B: IPL/Elight (IPL&RF) for hair removal, freckles removal, vascular and acne therapy, etc. There are 6 filters with different wavelength for different treating items.
C: Bipolar RF (20/28/35mm 3 treatment heads) for wrinkles removal, face lifting, skin tightening, etc.
D: Nd: Yag Laser for all kinds and colors tattoo removal, birthmark removal, eyebrow line/ eye line/ lip line, pigments removal. There are 3 probes with different wavelength (1064nm,532nm,1320nm)for treating different items.
Laser Probes:
532nm probe: the green one, output green light to remove the colorful/ brown tattoos, birthmark, etc.
1064nm probe: the yellow one, output white light to remove the black/ cyan tattoos, etc.
1320nm Carbon treatment head : the black one, for skin rejuvenation,skin lift ,skin whitening, shrink pores and blackheads removal, black doll etc.
Filters:
640--1200nm for hair removal
590--1200nm for spots removal freckle removal,remove red blood.
530--1200nm for skin rejuvenation,acne treatment,pigment removal,
Technical Data:
| Type | Multifunctional Beauty Machine |
| Operating Language | 6 kinds (can be customized) |
| Cooling System | Semiconductor Cooling+Air Cooling+Water Cooling |
| Output Power | 3000W |
| Input Power | AC110/220±10% 50HZ/60HZ |
| Weight | 65kg |
| Package Dimensions | 650mm*600mm*1250mm |
| OPT SHR System (Fast Hair Removal) | |
| Spot size | 20mm*60mm |
| Filter Wavelength | 640nm/690nm |
| pulse width modulation | 1-10ms |
| Frequency | 1-10 p/s ( shot continuously) |
| Energy | 1-50J/cm2 |
| Elight IPL System | |
| The First Pulse Width | 1--10ms, 0.1ms for adjustable unit |
| The First Pulse Delay | 1--100ms, 1ms for adjustable unit |
| Pulse Number | 1--10 |
| Discharge Interval | 2--4s |
| Wavelength | Optional from the 430nm--640nm to 1200nm |
| Energy | IPL Energy: 1--50J/cm² |
| RF Energy: 1--50J/cm² | |
| RF System | |
| Technology | Bipolar RF |
| Treatment Heads | 20mm/ 28mm/ 35mm |
| Laser System | |
| Wavelength | 1064nm & 532nm &1320nm |
| Spot Diameter | 1--6mm continuously adjustable |
| Energy of Monopulse | ≤600mj@1064nm ≤200mj@532nm |
| The Largest Energy | 1000mj |
| Q-switching Adjusting Method | Passive adjusting method |
| Work Frequency | 1--6HZ |
